Specifications
Breaking load (kg) [kg]: 272
Breaking load (lb) [lb]: 600
Footnote: Maximum working loads and breaking loads for blocks based on cam strengths.
Height (in) [in]: 5 3/8
Height (mm) [mm]: 137
Length (in) [in]: 5 5/8
Length (mm) [mm]: 143
Maximum line Ø (in) [in]: 7/16
Maximum line Ø (mm) [mm]: 12
Maximum working load (kg) [kg]: 136
Maximum working load (lb) [lb]: 300
Product Warning: DO NOT use Harken equipment for human suspension unless product is specifically certified and labeled for such use.
Sheave Ø (in) [in]: 3
Sheave Ø (mm) [mm]: 75
Weight (g) [g]: 514
Weight (oz) [oz]: 18
Width (in) [in]: 2 5/8
Width (mm) [mm]: 66
