Description
Specifications
Breaking load (kg) [kg]: 1700
Breaking load (lb) [lb]: 3750
Footnote: Maximum working loads and breaking loads for blocks based on cam strengths.
Holding power: 10:1
Length (in) [in]: 4 1/16
Length (mm) [mm]: 103
Maximum line Ø (in) [in]: 3/8
Maximum line Ø (mm) [mm]: 10
Maximum working load (kg) [kg]: 680
Maximum working load (lb) [lb]: 1500
Product Warning: DO NOT use Harken equipment for human suspension unless product is specifically certified and labeled for such use.
Shackle pin Ø (in) [in]: 1/4
Shackle pin Ø (mm) [mm]: 6
Shackle pin Ø (mm) [mm]: 6
Sheave Ø (in) [in]: 2 1/4
Sheave Ø (mm) [mm]: 57
Weight (g) [g]: 435
Weight (oz) [oz]: 15.4
