Specifications
Breaking load (kg) [kg]: 907
Breaking load (lb) [lb]: 2000
Holding power: 15:1
Length (in) [in]: 4 1/16
Length (mm) [mm]: 103
Maximum line Ø (in) [in]: 3/8
Maximum line Ø (mm) [mm]: 10
Maximum working load (kg) [kg]: 227
Maximum working load (lb) [lb]: 500
Product Warning: DO NOT use Harken equipment for human suspension unless product is specifically certified and labeled for such use.
Shackle pin Ø (in) [in]: 3/16
Shackle pin Ø (mm) [mm]: 5
Shackle pin Ø (mm) [mm]: 5
Sheave Ø (in) [in]: 2 1/4
Sheave Ø (mm) [mm]: 57
Weight (g) [g]: 104
Weight (oz) [oz]: 3.7
